REX
100551REX is an ultra slim flat steel radiator model in the Ultra Slim Collection. Ideal for space solutions.
Technical Specifications
| Product Code | Height (mm) | Width (mm) | Pipe Centres (mm) | Wall-to-Centre (mm) | Wall Projection (mm) | Weight (kg) | Volume (L) | Fuel Type | Watt ΔT50 | BTU ΔT50 | BTU ΔT70 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 13REX0940049000 | 940 | 490 | 50 | 31-51 | 61-81 | 11.0 | 0.6 | C | 409 | 1394 | 2144 |
| 13REX1720049000 | 1720 | 490 | 50 | 31-51 | 61-81 | 19.6 | 1.1 | C | 748 | 2550 | 3923 |
- Material: Steel DC01
- Max Working Pressure: 2 bar
- Connections: 1/2" BSP
- Guarantee: 5 years
