MANCHESTER
100549MANCHESTER is an ultra slim flat steel radiator model in the Ultra Slim Collection. Ideal for space solutions.
Technical Specifications
| Product Code | Height (mm) | Width (mm) | Pipe Centres (mm) | Wall-to-Centre (mm) | Wall Projection (mm) | Weight (kg) | Volume (L) | Fuel Type | Watt ΔT50 | BTU ΔT50 | BTU ΔT70 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 13MAN0790047000 | 790 | 470 | 50 | 31-51 | 61-81 | 10.8 | 0.6 | C | 360 | 1228 | 1889 |
| 13MAN1190047000 | 1190 | 470 | 50 | 31-51 | 61-81 | 15.5 | 0.9 | C | 517 | 1762 | 2711 |
- Material: Steel DC01
- Max Working Pressure: 2 bar
- Connections: 1/2" BSP
- Guarantee: 5 years
