DUBLIN
100545DUBLIN is an ultra slim flat steel radiator model in the Ultra Slim Collection. Ideal for space solutions.
Technical Specifications
| Product Code | Height (mm) | Width (mm) | Pipe Centres (mm) | Wall-to-Centre (mm) | Wall Projection (mm) | Weight (kg) | Volume (L) | Fuel Type | Watt ΔT50 | BTU ΔT50 | BTU ΔT70 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 13DUB0450045000 | 450 | 450 | 50 | 31-51 | 61-81 | 5.5 | 0.3 | C | 183 | 625 | 962 |
| 13DUB1790045000 | 1790 | 450 | 50 | 31-51 | 61-81 | 22.6 | 1.3 | C | 753 | 2569 | 3952 |
- Material: Steel DC01
- Max Working Pressure: 2 bar
- Connections: 1/2" BSP
- Guarantee: 5 years
