TERRA L
100420TERRA L — Aluminium towel rail. Modern bathroom design, AluRapid thermal response.
Technical Specifications
| Product Code | Height (mm) | Width (mm) | Sections | Pipe Centres (mm) | Wall-to-Centre (mm) | Wall Projection (mm) | Weight (kg) | Volume (L) | Fuel Type | Watt ΔT50 | BTU ΔT50 | BTU ΔT70 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 15TRL0800050008 | 800 | 500 | 8 | 50 | 66-86 | 109-129 | 5.3 | 1.1 | D | 284 | 968 | 1489 |
| 15TRL1600050016 | 1600 | 500 | 16 | 50 | 66-86 | 109-129 | 10.6 | 2.3 | D | 567 | 1935 | 2977 |
- Material: Aluminium 6063-T5
- Max Working Pressure: 10 bar
- Connections: 1/2" BSP
- Guarantee: 10 years
