ELEGANS
100534ELEGANS is a stainless steel towel rail model. Listed with dimensions and performance options from the technical table for vertical space solutions.
Technical Specifications
| Product Code | Height (mm) | Width (mm) | Sections | Pipe Centres (mm) | Wall-to-Centre (mm) | Wall Projection (mm) | Weight (kg) | Volume (L) | Fuel Type | Watt ΔT50 | BTU ΔT50 | BTU ΔT70 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 16ELG0800050005 | 800 | 500 | 5 | 50 | 60-75 | 102-117 | 5.0 | 3.5 | D | 253 | 861 | 1325 |
| 16ELG1800050009 | 1800 | 500 | 9 | 50 | 60-75 | 102-117 | 9.9 | 6.8 | D | 455 | 1553 | 2389 |
- Material: Stainless Steel 304
- Max Working Pressure: 10 bar
- Connections: 1/2" BSP
- Guarantee: 20 years - Brushed/Polished; 5 years - Paint; 2 years - PVD
